BK 02F
BK 02F

Wood fireplaces

BK 02F

wood-burning fireplace

Double-sided wood-burning fireplace with natural convection with vision of the fire on two sides. Both doors are in ceramic glass: the front one can be hinged with a stainless steel handle and hinged door to facilitate cleaning, while the rear one can be hinged. Structure in thick steel, combustion chamber and fire bed in ceramic refractory. Suitable for central installation as well as for the separation of living spaces.

BK 02F

BK 02F
European reference standard for inserts and fireplaces European Directive for biomass domestic appliances: stoves, fireplaces and kitchens (Regulations UE 2015/1185) European standards conformity mark
Find reseller Request information

Technical data

  classe-AA
  BK 02F
  natural convection
output 13,0 kW
nominal thermal output 11,0 kW
CO emission at 13% oxygen 0,09 %
efficiency 84,4 %
average fuel consumption 3,7 kg/h
flue gas mass flow 8,2 g/s
flue gas temperature 254 °C
flue draught pressure 11 Pa
flue exite pipe Ø 200 mm
internal section of chimney flue Ø 20 cm
min. height of chimney flue 4 m
air inlet ducts Ø 15 cm
net weight 269 kg
weight with packaging 289 kg
